Start - stop
Soft start and soft stop in 0 positions
Size of pack (l x w x h)
(80-200 x 10-75 x 40-80mm)
Dimensions (l x w x h)
(3.990mm x 1.650mm x 1.650mm)
Machine Weight
800 kg
Reel (Max outer dia / core dia)
300 / 75 mm
Reel (Conveyor) Length
Standard, 114"
Machine Capacity
up to 150 packs / minutes
Electric Motor
(1) 1 hp. (2) 2 hp
Machine Load
10amp (2kw)
Standard Equipment
Photo Electric Eye & Invertor
Packing Material
Liquid over Wrap
Voltage and frequency
220vac, single phase, 50 Hz
Weight of Packing Material
2gm to 400gm
Sealing Type
3 Side and Centre Sealing
Heaters size
4" to 6"
Usage / Application
Face wash, Hair Color, Hair Remover, Bleach Cream
